Ultrasonic testing uses high frequency, highly directional sound waves to measure material thickness, find hidden internal flaws, or analyze material properties in metals, plastics, composites, ceramics, rubber, and glass. Using frequencies beyond the limit of human hearing, ultrasonic instruments generate shorts bursts of sound energy that are coupled into the test piece, and the instrument monitors and analyzes reflected or transmitted wave patterns to generate test results.

• Sound Velocity: 1000 - 9999m/sec
• Range (steel): 0.75 - 80mm
• Resolution: 0,1 mm
• Sensor: 7MHz Ø 6mm
• Accuracy: 0,5% of Measured Value

• Dimensions: 150 x 75 x 32mm
• Weight: 245g;
• External sensor for better access to the test object (Cable length: 1 m).
• Scan mode (10 measurements per sec.) or single point measuring mode possible.
• RS 232 Output included
• Internal memory for 20 les (with up to 100 values per file)
• Auto-Power-Off function
• Control plate for calibration included (2 point calibration).
• Hard carrying case included
• Power supply 2 x 1.5V AA Batteries
• Warranty: 24 months
